ขายแอมป์พกพา Sunrise Ray Amplifier + USB DAC ชิปWolfson WM8740 + TI PCM2706 บอดี้อลูมิเนียมทั้งตัว

Description

Sunrise ultra portable DAC/AMP combo MODEL "RAY" is our entry level audio solution, which is a Self powered DAC and Hi-Definition headphone amplifier. As an entry level product, Ray is an inexpensive product but provide truly high quality audio solution. We choose the Wolfson 24bit Hi-performance DAC chip WM8740 and Texas Instruments’ PCM2706 as the USB receiver which were widely recognized in audiophile world. The AMP section is not like other entry level product that use cheap all-in-one headphone amplification IC, such as the TPA6130A. The AMP section in the "RAY" is based on the AD8656 and well tuned with some high quality audio capacitors in special circuit. “RAY" is super mini size with only 15mm thickness. Hard to believe but "RAY" will make your PC/Laptop sound like a full HIFI source.

Specification

Ÿ            Plug and Play, Compliance with USB specification standard, Available for Windows and Macos
Wolfson WM8740 DAC Chip + TI PCM2706 USB Receiver

Ÿ            Works as a DAC/AMP Combo or a stand-alone AMP.

Ÿ            Rechargeable Li-polymer battery with integrated charging system, 30 hours play time.

Ÿ            Slim and small, ultra-portable design.

Ÿ            Product Size:90mm*60mm*15mm(L*W*H)

Ÿ            Weight: Approx.120g

Ÿ            Output Power : ＞250mW (16Ω loaded)

＞36mW (300Ω loaded)

Ÿ            Headphone Load Impedance : 16~300Ω

Ÿ            Distortion: ＜0.001% （AMP）

＜0.007% （DAC）

Ÿ            Frequency response : 10Hz-100KHz(AMP)

10Hz-20KHz(DAC)

Ÿ            Battery capacity: 1500Mah
